| NO | PART NAME | MATERIAL |
|---|---|---|
| 1 | Body | GG 25 / GGG 40 |
| 2 | Bonnet | GG 25 / GGG 40 |
| 3 | Ball | EPDM |
| 4 | Gasket | EPDM |
| 5 | Bolt / Nut | 8,8 / 8 |
| Nominal Pressure | Nominal Diameter | Valve Dimensions | PN16 Threaded Dimensions DIN EN 10226-1 | Weight | |||
|---|---|---|---|---|---|---|---|
| PN | DN | L | H | Ød1 | t | AA | kg |
| 16 | 25 | 125 | 80 | 1” | 17 | 50 | 1,7 |
| 32 | 135 | 85 | 1 1/4" | 25 | 65 | 2,4 | |
| 40 | 151 | 105 | 11/2" | 27 | 75 | 3 | |
| 50 | 175 | 125 | 2" | 31 | 90 | 4 | |
| 65 | 202 | 135 | 21/2" | 31 | 95 | 5,5 | |
| Pressure Rate | : | PN 16 |
| End | : | EN 10226 Threaded |
