| Design | : | EN 1171 |
| Face to Face | : | EN 558 Serie 14 (DN3202 F4) |
| Pressure Rate | : | PN10-PN16 |
| Size Range | : | DN40-DN1000 |
| Temperature | : | -10....+120 oC |
| Flange Ends | : | DIN EN 1092-2/B |
| Tests | : | EN 12266 |
| Design | : | EN 1171, DIN 3352 |
| Face to Face | : | EN 558 Serie 14, DIN 3202 F4 |
| Pressure Rate | : | Max. PN16 |
| Size Range | : | DN40-DN600 |
| Temperature | : | -10... +120°C |
| Flange Ends | : | DIN EN 1171 |
| Tests | : | EN 12266 |
| Design | : | DIN 1171 / DIN 3352 |
| Face to face | : | DIN 3202-F5 / EN 558-S15 |
| Flange end | : | EN 1092 |
| Test | : | EN 12266 |
| Size | : | DN 15 - DN600 |
| Pressure | : | PN 10-16-25-40 |
| Ends | : | DIN EN 1092 (Flange) |
| Dimensions | : | DIN3356/2-F1 (Straight) DIN EN 558-1-1 |
| Tests | : | DIN EN 12266 |
| Options | : | Regulating Disc, ANSI Flange |
| Pressure Rate | : | PN 10 - PN 40 |
| Size Range | : | DN15-DN600 |
| Ends | : | DIN 2533 (Flange) |
| Dimensions | : | DIN 3356/2-F1(Straight) DIN 3356/2-F32(Angle) |
| Conical disc, bolted, bonnet (BB) |
| Check Valves (SDNR) - Flanged (FLGD) - Class 150 - Rising Stem and Handwheel (RS) |
| TEST API 598 - Outside screw and yoke (OSY) |
| ANSI B16,10 - Bolted Gand (BG) |
| ANSU B16,5/Flange |
| Design | : | DIN 3356-1 Short Pattern |
| Face to Face | : | VisVana Design |
| Pressure | : | PN 16 |
| Size Range | : | DN15-DN200 |
| Flange Ends | : | EN 1092-3/A |
| Options | : | SDNR Type, Regulating Disc |
| Tests | : | EN 12266 |
| Design | : | Union Bonnet, Short Pattern |
| Face to Face | : | VisVana Design |
| Pressure | : | PN 16 |
| Size Range | : | DN15-DN100 |
| Flange Ends | : | EN 1092-3/A |
| Options | : | Regulating Disc |
| Tests | : | EN 12266 |
| Design | : | DIN 3356-1 Short Pattern |
| Center to Face | : | VisVana Design |
| Pressure | : | PN 16 |
| Size Range | : | DN15-DN200 |
| Flange Ends | : | EN 1092-3 |
| Options | : | SDNR Type, Regulating Disc |
| Tests | : | EN 12266 |
| Pressure Rate | : | PN16-PN10 |
| Size Range | : | DN15-DN100 |
| Flange Ends | : | DIN EN 1092 |
| Test | : | DIN EN 12266 |
| Options | : | Bronze RG7, RG10, CuSn10 |
| Pressure Rate | : | PN16-PN10 |
| Size Range | : | DN15-DN100 |
| Flange Ends | : | DIN EN 1092 |
| Test | : | DIN EN 12266 |
| Design | : | JIS F7301 STOP JIS F7351 SDNR |
| Pressure Rate | : | 5K |
| Size Range | : | DN15- DN65 |
| Temperature | : | Steam < 205°C |
| Water <120°C | ||
| Flange Ends | : | JIS B2240 - 5K |
| Inspection | : | JIS F7400 |
| Application | : | Air, Gas, Oil, Pulsation Water |
| Design | : | JIS F7302 STOP JIS F7352 SDNR |
| Pressure Rate | : | 5K |
| Size Range | : | DN15-DN65 |
| Temperature | : | Steam < 205°C |
| Water < 120°C | ||
| Flange Ends | : | JIS B2240 - 5K |
| Inspection | : | JIS F7400 |
| Application | : | Air, Gas, Oil, Pulsation Water |
| Design | : | JIS F7303 STOP JIS F7409 SDNR |
| Pressure Rate | : | 16 K |
| Size Range | : | DN15-DN40 |
| Temperature | : | Steam < 205 ºC |
| Water | : | < 120 ºC |
| Flange Ends | : | JIS B2240 - 16K |
| Inspection | : | JIS F7400 |
| Application | : | Air, Gas, Oil, Pulsation Water |
| Design | : | JIS F7304 STOP / JIS F7410 SDNR |
| Pressure Rate | : | 16K |
| Size Range | : | DN15-DN40 |
| Temperature | : | Steam < 205 °C Water < 120 °C" |
| Flange Ends | : | JIS B2240 - 16K |
| Inspection | : | JIS F7400 |
| Application | : | Air, Gas, Oil, Pulsation Water |
| Pressure Rate | : | 16 Bar |
| Size Range | : | DN15-DN50 |
| Ends | : | BSPT |
| Temperature | : | <170°C |
| Application | : | Water, Oil and Gas. |
| Pressure Rate | : | 16 Bar |
| Size Range | : | DN15-DN50 |
| Ends | : | BSPT |
| Temperature | : | < 170 °C |
| Application | : | Water, Oil and Gas. |
| Pressure Rate | : | PN10-16-25-40 |
| Face to Face | : | DIN EN 558-1-48 |
| Temperature | : | -10....+120 ºC |
| Flange Ends | : | DIN EN 1092 DIN EN 12266 & API 598 Tests |
| Nominal Diameter | : | DN15-DN600 |
| Nominal Pressure | : | PN16-40 |
| Ends | : | DIN 2533 (Flanş) |
| Dimensions | : | DIN 3202/ 2 F32 TS 10873 |
| PN 16-40 |
| DIN 3202/2-K4 |
| ISO 5752 |
| DIN 2501(Flanş) |
| DN 15/100 - 125/200 |
| Nominal Diameter | : | DN40-DN300 |
| Nominal Pressure | : | PN10-16 |
| Ends | : | DIN 2501(Flange Ends) |
| Temperature | : | -10 ºC+120 ºC (DIN 2401-2) |
| Dimensions | : | DIN 3202-F6 |
| Pressure Rate | : | PN10-16-25-40 |
| Face to Face | : | DIN EN 558-14 |
| Temperature | : | -10...+120 ºC |
| Flange Ends | : | DIN EN 1092 |
| DIN EN 12266 & API 598 Tests | ||
| DIN EN 558-1-16 | ||
| Pressure Rate | : | PN10-16-25 |
| Temperature | : | -10...+120 ºC |
| Flange Ends | : | DIN EN 1092, DIN EN 12266 & API 598 Tests DIN EN 558-1-16 |
| Sandwhich Type | ||
| Pressure Rate | : | PN 10-16 |
| Flange Ends | : | DIN 2501 |
| DN 40....800 | ||
| Nominal Pressure | : | PN16-25 DN 50 / DN 600 DIN 3337 / K1 TS 11341 |
| Nominal Pressure | : | PN16 DN 50 / DN 600 DIN 3337/K1 TS 11341 |
| Size Range | : | DN 40 / DN 1400 |
| Pressure Rate | : | PN 10/16/CLASS 150 |
| Flange Ends | : | DIN EN 1092 |
| Dimensions | : | DIN 3337/K1 DIN EN 558-1-20 |
| Size Range | : | DN 40 / DN 1400 |
| Pressure Rate | : | PN 10/16/CLASS 150 |
| Flange Ends | : | DIN EN 1092 |
| Dimensions | : | DIN 3337/K1 DIN EN 558-1-20 |
| Design | : | JIS F7480 Series 122 |
| Pressure Rate | : | 5K / 10K |
| Temperature | : | -10~80 °C |
| Size Range | : | DN50-DN150 |
| Flange Ends | : | JIS B2210 - 5K / 10K |
| Inspection | : | JIS F7400 |
| Application | : | Sea water, cold and warm water |
| Pressure Rate | : | PN 4 |
| Size Range | : | DN40 - DN400 |
| Flange Ends | : | DIN EN 1092 (PN 10 Flange) DIN 87 151-D Straight |
| Dimensions | : | DIN 87 151-E Angle |
| Tests | : | DIN EN 12266 |
| Nominal Pressure | : | DN 40 - DN 600 PN 4 / DN 500 - 600 DN 2,5 |
| Nominal Diameter | : | DN40 - DN600 |
| Dimensions | : | DIN87 151 - D Straight DIN EN 12266 |
| Options | : | ANSI, JIS Flanges |
| Pressure Rate | : | PN 4 |
| Size Range | : | DN 40 - DN 40 400 |
| Flange Ends | : | DIN EN 1092 (PN10Flange) |
| Dimensions | : | DIN 87 151 - E Angle DIN 87 151 - D Straight |
| Tests | : | DIN EN 12266 |
| Design | : | JIS F3060 Straight Type |
| Pressure Rate | : | 5K / 10K |
| Size Range | : | DN50-DN150 |
| Flange Ends | : | JIS B2239 - 5K / 10K |
| Inspection | : | JIS F7400 |
| Application | : | Aboard ships for Wastewater |
| Design | : | JIS F3060 |
| Pressure Rate | : | 5K / 10K |
| Size Range | : | DN50 - DN150 |
| Flange Ends | : | JIS B2239 - 5K / 10K |
| Inspection | : | JIS F7400 |
| Application | : | Aboard ships for Wastewater. |
| Pressure Rate | : | PN 16 |
| Size Range | : | DN15 - DN200 |
| Dimensions | : | DIN 3202 / 2- F32 (Angle) |
| Flange Ends | : | DN 2533 |
| Options | : | ANSI, JIS Flanges |
| Pressure Rate | : | PN 16 |
| Size Range | : | DN15-DN200 |
| Dimensions | : | DIN 3202/2-F1(Straight) |
| Flange Ends | : | DN 2533 |
| Options | : | ANSI, JIS Flanges |
| Pressure Rate | : | PN 16 |
| Size Range | : | DN15 - DN 100 |
| Dimensions | : | DIN 3356/2 - F1 (Straight) DIN 3356 /2 -F32 |
| Ends | : | DIN EN 1092-1-2 |
| Pressure Rate | : | CLASS 150 |
| Size Range | : | DN15 - DN 100 |
| Dimensions | : | DIN 3202 / 2-F (Straight) |
| Flange Ends | : | ANSI B165 RF |
| Tests | : | API 598 / DIN EN 12266 |
| Options | : | ANSI JIS Flanges |
| Pressure Rate | : | PN16 |
| Size Range | : | DN40-DN250 |
| Flange Ends | : | DIN EN 1092 |
| Dimensions | : | DIN HNA-PN16 |
| FULL BORE - THREADED | ||
| Pressure Rate | : | PN 2,5 DIN 86 120 |
| Size Range | : | DN32-DN65(11/4” - 21/2”) DIN 259 / ISO / R 228 |
| FULL BORE - THREADED | ||
| Pressure Rate | : | PN2,5 DIN 86 120 |
| Size Range | : | DN32-DN65(11/4"-21/2") DIN 259 / ISO / R 228 |
| Pressure Rate | : | PN 16 |
| Size Range | : | DN20- DN40 |
| Ends | : | DIN EN 1092-1-2 DIN EN 10226-1 |
| Pressure Rate | : | PN 16 |
| Size Range | : | DN15 - DN300 |
| Flange Ends | : | DIN 2533 |
| Flange Ends | : | DIN 3356/2-F1 (Straight) DIN 3356/2-F32 (Angle) |
| Pressure Rate | : | 20 Bar |
| Size Range | : | DN15-DN100 |
| Ends | : | BSPT |
| Temperature | : | <170 Cº |
| Application | : | Water and Gas. |
| Out Pressure DN15....25 | : | 1~4 bar |
| Out Pressure DN32....100 | : | 1~5 bar |
| Pressure Rate | : | 20 Bar |
| Size Range | : | DN8-DN100 |
| Ends | : | BSP |
| Temperature | : | < 170 °C |
| Application | : | Water, Oil and Gas. |
